Vessel’s Specification
Ship Name：
***
IMO No.：
-
Ship Type：
Fully Revolving Floating Crane
Class：
ZC
Built Place：
China
Navigation Area：
A1+A2
Flag：
China
Built Date：
2016.04
Loa：
46M
Breadth：
16.6M
Depth：
2.6M
Draft：
1.1M
GT：
849T
NT：
254T
Crane Brand：
JS
Crane Model：
JS-40
Brand of crane driving machine：
YZR400L2-10
Power of crane driving machine：
160kw
Max. Lifting Capacity：
25T
Max. Lifting Height：
30M
Max. Working Radius：
7M
Lifting Speed：
1m/s
Length Boom：
32.5M
ME Brand：
Yulin diesel engine
Main Engine Model：
YC6MJ410L-C20
ME Power：
600kw
RPM：
1800R/Min
Speed：
- KN
Aux. Engine Brand：
Yulin diesel engine
Aux. Engine No.：
1
Aux. Engine Power：
550kw
Oil Consumption：
- T/D
Main Engine No：
Double
Self-propelled or not：
yes
NOx emission standard of diesel engine：
Tier II
Release Date：
2021.04.01
Certificates, Drawings
Certificate of Inspection：
yes
General Arrangement Plan (GA)：
No
Certificate of Ship Ownership：
No
Certificate of Registry：
No
Ship Equipment List：
yes
Remarks
The ship has self-propelled ability， two 300KW Yuchai main engines， shorter range.
