Ship parameters
Ship Type
AHTS
Navigation Area
A1+A2+A3
Class
ABS
Built Place
Malaysia
Flag
Malaysia
Built Date
2010.12
Loa
61.25M
Breadth：
16M
Depth：
6M
Draft
5.1M
DWT
1791T
GT
1976T
NT
592T
Deck Area
370㎡
Deck Loading
7.5t/㎡
Capstan
10T
Tugger
10T
Bollard pull
61.2T
Liquid Mud/Brine
245m³
ME Brand
Niigata
Main Engine Model
6MG28HX
ME Power
3676kw
RPM
750R/Min
Speed
12.5KN
Aux. Engine Brand
Caterpillar
Aux. Engine No.
3
Aux. Engine Power
245kw
Oil Consumption
11T/D
Main Engine No.
Double
Anchor Handling
yes
Fire Fighting Level
LEVEL ONE
Propulsion type
CONTROLLABLE PITCH
Positioning System
DP1
NOx emission standard of diesel engine
Tier I
